Jet 101016 1 Ton 20' Lift VCH Series Chain Hoist
1 Ton 20' Lift VCH Series Chain Hoist (101016)
- Triple spur geared for efficient operation
- Hardened steel roller bearings support load sheave for easy operation
- Dual pawl Weston style brake for safe reliable operation
- Exclusive premium grade, non-asbestos brake discs for longest life
- Grade 80 load chain
- Top and bottom safety hooks bend slowly to warn of overloads
- Load tested to 150% of rated capacity with certificate
- Meets ASME B30.16 standards
- ISO 9001-2000 certified factory
- NOTE: Custom Lifts are available in any length desired.
- Product Weight (lb/kg) 35.42 lb (16.1 kg)
- Rated Lifting Capacity (Tons) 1
- Rated Lifting Capacity (lbs) 2,200
- Standard Lift 20'
- Head Room 12-1/16"
- Number of Falls 1
- Load Chain Diameter 6.0mm
- Force Req. to Lift Capacity (lbs) 68
- Length of Hand Chain Pulled to Lift Load 1 ft 40'
- A 5-3/4"
- B 5-1/2"
- C 45mm
- G 33mm
- H 12-1/16"
* All Pictures Shown Are For Illustration Purpose Only. Actual Product May Vary Due To Product Enhancement.
