Jet 101036 2 Ton 20' Lift VCH Series Chain Hoist

SKU: JET101036:EA Available on Backorder
Regular price $451.30
2 Ton 20' Lift VCH Series Chain Hoist (101036)
  • Triple spur geared for efficient operation
  • Hardened steel roller bearings support load sheave for easy operation
  • Dual pawl Weston style brake for safe reliable operation
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Grade 80 load chain
  • Top and bottom safety hooks bend slowly to warn of overloads
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory
  • NOTE: Custom Lifts are available in any length desired.
Specifications:
  • Product Weight (lb/kg) 54.692 lb (24.86 kg)
  • Rated Lifting Capacity (Tons) 2
  • Rated Lifting Capacity (lbs) 4,400
  • Standard Lift 20'
  • Head Room 17-1/2"
  • Number of Falls 1
  • Load Chain Diameter 8.0mm
  • Force Req. to Lift Capacity (lbs) 102
  • Length of Hand Chain Pulled to Lift Load 1 ft 70'
  • A 7-1/4"
  • B 6-1/4"
  • C 52mm
  • G 33.5mm
  • H 17-1/2"

* All Pictures Shown Are For Illustration Purpose Only. Actual Product May Vary Due To Product Enhancement.
