Jet 101136 Model KCH-2020 2 Ton 20' Lift KCH Series Chain Hoist

Jet 101136 Model KCH-2020 2 Ton 20' Lift KCH Series Chain Hoist

Jet

Out of Stock

  • $661.52


  • Triple spur geared for efficient operation
  • Maintenance free sealed bearings reduce operator effort
  • Dual pawl Weston style brake with extra heavy pawl springs for safe reliable operation
  • Extra thick ratchet gear protects brake disc from contamination
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Grade 100 load chain for greater strength
  • Top and bottom safety hooks bend slowly to warn of overloads
  • Cast safety latches exceed industry standards
  • Specialized finish on key internal parts for superior corrosion resistance
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory

Specifications:

  • A: 7-1/4"
  • B: 8"
  • C: 2-1/2"
  • D: 1-3/8"
  • E: 37 mm
  • F: 46 mm
  • Force Req. to Lift Capacity: 79 lb
  • G: 52 mm
  • H: 14-3/4"
  • Head Room: 14-3/4"
  • Length of Hand Chain Pulled to Lift Load 1': 70'
  • Load Chain Diameter: 8.0 mm
  • Number of Falls: 1
  • Product Weight: 59.62 lb (27.1 kg)
  • Rated Lifting Capacity:
    • 4,400 lb
    • 2 T
  • Shipping Weight: 60.6 lb (27.6 kg)
  • Standard Lift: 20'

* All Pictures Shown Are For Illustration Purpose Only. Actual Product May Vary Due To Product Enhancement.
